1. Aerodynamics Lab, equipped with subsonic wind tunnel and smoke tunnel, provides opportunities to study aerodynamic characteristics & flow patterns on different aerofoil, circular cylinder and aircraft test models.
Lab equipment available are,
- Wind tunnels
- Smoke tunnel
- 3 Component force balance
- Hot wire anemometer
- 16 Channels pressure scanner
- Reynolds apparatus
-
WIND TUNNEL
-
CO-AXIAL JET FLOWS, WIND TUNNEL
-
FLOW VISUALIZATION SET UP
-
REYNOLDS APPRATUS
-
SMOKE TUNNEL
-
Fully digital subsonic wind tunnel
